CTI Workbench Integrated Development Environment for IEC-61131

The CTI Workbench Integrated Development Environment is a powerful Windows-based tool for developing and debugging automation applications on the 2500P-ACP1 Advanced Communication Coprocessor.

Features

  • Works with Windows® 7 or greater, any version
  • Fully supports all five language of the IEC 61131-3 standard
  • Program editors for
    • Function Block Diagram (FBD)
    • Structure Text (ST) and Instruction List (IL)
    • Ladder Diagram (LD)
    • Sequential Function Chart (SFC)
  • Full support of OLE drag and drop in all editors
  • Powerful auto-documentation feature (HTML)
  • Quick editing with just-in-time variable declaration
  • Fieldbus configuration tool supporting
    • CAMP Client (for communications over Ethernet to other CTI products)
    • Network Data Exchange (for publish/subscribe communications to other CTI products supporting it)
    • MODBUS Master/Slave (using Ethernet OR Serial ports on 2500P-ACP1)
  • Auto-indentation in ST languages
  • Full syntax coloring
  • Auto-completation of variable and function name
  • Monitoring tools for viewing variable and program status in real-time
  • Extensive online debugging tools
  • Optional program source storage on the 2500P-ACP1
  • Network Communications Supported (2500P-ACP1)
    • CAMP Client (TCP, UDP, Multicast)
    • Open Modbus (Client, Server)
    • Ethernet/IP (I/O Scanner, I/O Adapter, Explicit Message Adapter, Tag Client)
    • Serial Modbus (Master, Slave)
    • General ASCII (Send, Receive)
    • Network Data Exchange

Files and Documents

PUBLIC (NO LOGIN REQUIRED)


Application Notes

RESTRICTED (LOGIN REQUIRED)

(NOTE: this software runs as a full featured demo if no USB dongle is installed.  But can be started only 15 times before demo mode expires.  Contact CTI for other demo arrangements if needed)
Workbench Key Upgrade Procedure

YouTube Tutorials
